| General | |
|---|---|
| Recomandat Gaming | Da |
| Placa audio integrata | 7.1 Audio |
| Chipset audio | Realtek ALC4082 DAC (ESS ES9219Q) |
| RAID | 0, 1, 10 |
| Placa video integrata | Necesita procesor cu tehnologia AMD Radeon Graphics |
| Placa retea integrata | 10/100/1000/2500/5000 Mbps 10/100/1000/2500/5000/10000 Mbps |
| Chipset retea | Realtek RTL8126 Marvell AQtion AQC113CS |
| BIOS | 256 Mbit AMI UEFI BIOS |
| Interfata grafica | PCI Express x16 5.0 |
| SATA III | 4 |
| NGFF (M.2) | 6 |
| Procesor | |
| CPU Socket | AM5 |
| Chipset | X870E |
| Producator chipset | AMD |
| Procesoare suportate | AMD Ryzen 7000/8000/9000 Series |
| Memorie | |
| Model memorie | DDR5 |
| Capacitate maxima memorie RAM | 256 GB |
| Tehnologie | Dual channel |
| Frecvente suportate | 9000 - 5600 (OC) MHz 5600 - 4800 (JEDEC) MHz |
| Sloturi memorie | 4 |
| Sloturi | |
| PCI Express 4.0 | 1 (x4) |
| PCI Express 5.0 | 2 (x16 / x0 , x8 / x8) |
| Conectivitate | |
| Iesire optica S/PDIF | 1 |
| Clear CMOS | 1 |
| RJ-45 | 2 |
| USB 3.2 Gen2 tip A | 8 |
| USB tip C | 2 x USB-C 4 5 x USB-C 3.1 |
| Suport audio | 7.1 |
| Audio jacks | 2 |
| Wireless | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) |
| Bluetooth | Bluetooth 5.4 |
| Thunderbolt | 2 via USB-C |
| BIOS Flashback | 1 |
| Conectori speciali | 1 x Buton Smart 2 x SMA conectori antena |
| Specificatii Fizice | |
| Format | eATX |
| Dimensiuni (L x l, cm) | 304.8 x 276.9 mm |
