| Procesor | |
|---|---|
| CPU Socket | 1151 v2 |
| Producator chipset | Intel |
| Model Chipset | Intel B360 |
| Numar procesoare | 1 |
| Chipset | Intel® B360 |
| Procesoare suportate | 8th Generation Intel® Core™ |
| Sloturi | |
| Slot PCI-Express x1 | 4 x PCI Express 3.0 x1 |
| Slot PCI-Express x16 | 2 x PCI Express x16 |
| Altele | |
| Format | ATX |
| BIOS | AMI UEFI Legal BIOS |
| Dimensiuni (L x l, cm) | 30.5 x 24.4 |
| Altele | CASE OPEN detection Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans Temperature Sensing: CPU, CPU/Water Pump, Chassis/Water Pump Fans Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V, VCCSA, VCCST |
| Caracteristici BIOS | SMBIOS 2.7 Support 128Mb ACPI 6.0 Compliant wake up events CPU Core/Cache, GT Core/Cache, DRAM, PCH 1.0V, VCCIO, VCCST, VCCSA, VCCPLL, CPU Internal PLL, GT PLL, Ring PLL, System Agent PLL, Memory Controller PLL Voltage Multi-adjustment |
| Caracteristici speciale | ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Intel® 4-Layer Memory POOL (Planes on Outer Layers) Technology ASRock Live Update & APP Shop ASRock Steel Slots ASRock Super Alloy ASRock USB 3.1 Gen2 ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3) |
| Sisteme de operare testate | Windows® 10 64-bit |
| Memorie | |
| Memorii suportate | DDR4 |
| Sloturi memorie | 4 x DDR4 |
| Capacitate maxima memorie RAM (GB) | 64GB |
| Frecventa memorie (MHz) | 2666 / 2400 / 2133 |
| Conectivitate | |
| Porturi USB 3.1 | 5 x USB 3.1 |
| Porturi USB 2.0 Spate | 2 x USB 2.0 |
| LAN integrat | Giga PHY Intel® I219V |
| Video integrat | Integrat in CPU |
| Audio integrat | Realtek ALC1220 Audio Codec |
| Interfata Serial ATA | SATA3 |
| Numar SATA | 6 x SATA 3 |
| Porturi USB | 1 x USB 3.1 Gen1 1 x USB 3.1 Gen2 Type-A 1 x USB 3.1 Gen2 Type-C 2 x USB 2.0 2 x USB 2.0 spate 2 x USB 3.1 Gen1 |
| Antena | 2 |
| Audio | HD Audio |
| Conectori interni | 1 x CPU Fan Connector (4-pin) 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) 1 x Addressable LED Header 1 x COM Port Header 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) 1 x Chassis Intrusion header 1 x Front Panel Audio Connector (15μ Gold Audio Connector) 1 x Power LED and Speaker Header 1 x TPM Header 1 x Thunderbolt™ AIC Connector (5-pin) 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) 2 x RGB LED Headers 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) |
| D-Sub | 1 |
| DisplayPort | 1 |
| HDMI | 1 |
| M2 | 2 |
| PS/2 Mouse/Keyboard | 1 |
| RJ45 | 1 |
| S/PDIF Out (Optical) | 1 |
