| Procesor | |
| CPU Socket: |
1700
|
| Producator chipset: |
Intel
|
| Model Chipset: |
Intel Z690
|
| Procesoare suportate: |
Supports 12th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors 1
|
| Sloturi | |
| Slot PCI-Express x16: |
3 x PCI Express x16
|
| Memorie | |
| Memorii suportate: |
DDR5
|
| Sloturi memorie: |
4 x DDR5
|
| Conectivitate | |
| LAN integrat: |
2x Intel® I225V 2.5Gbps LAN controllers
Intel® Wi-Fi 6E
|
| Audio integrat: |
Realtek® ALC4082 Codec + ESS SABRE9018Q2C Combo DAC/HPA
|
| Numar SATA: |
6 x SATA 3
|
| Conectori interni: |
1x 24-pin ATX main power connector
1x 3-pin Water Flow connector
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
1x Chassis Intrusion connector
1x Front panel audio connector
1x TPM module connector
1x Tuning Controller connector
2x 2-pin Thermal sensor connectors
2x 8-pin ATX 12V power connectors
2x System panel connectors
2x USB 2.0 Type-A connectors (supports additional 4 USB 2.0 ports)
2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4 USB 3.2 Gen 1 5Gbps ports)
2x USB 3.2 Gen 2x2 20Gbps Type-C ports
5x M.2 slots (M-Key)
6x 4-pin system fan connectors
6x SATA 6Gb/s connectors
|
| M2: |
5
|
| Porturi: |
1 x Clear CMOS Button
2 x 2.5G LAN
Flash BIOS Button
HD Audio Connectors
Mini DisplayPort Input (for Thunderbolt passthrough)
Optical S/PDIF-Out
Thunderbolt 4 40Gbps (Type-C)
USB 3.2 Gen 2 10Gbps (Type-A)
USB 3.2 Gen 2 10Gbps (Type-C Display port)
Wi-Fi / Bluetooth
|
| RAID: |
Supports RAID 0, RAID 1 , RAID 5 and RAID 10 for M.2 NVMe storage devices
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
|
| Altele | |
| Format: |
Extended ATX
|
| Dimensiuni (L x l, cm): |
30.5 cm x 27.7 cm
|
