| Procesor | |
|---|---|
| CPU Socket | 1151 v2 |
| Producator chipset | Intel |
| Model Chipset | Intel B360 |
| Numar procesoare | 1 |
| Chipset | Intel® B360 |
| Procesoare suportate | 8th Gen Intel® Core™, Pentium® Gold, Celeron® |
| Sloturi | |
| Slot PCI-Express x1 | 4 x PCIe 3.0 x1 |
| Slot PCI-Express x16 | 2 x PCI Express x16 |
| Altele | |
| Format | ATX |
| Dimensiuni (L x l, cm) | 30.4 x 24.3 |
| Caracteristici speciale | Audio Boost Core Boost DDR4 Boost EZ Debug LED X-Boost |
| Memorie | |
| Memorii suportate | DDR4 |
| Sloturi memorie | 4 x DDR4 |
| Capacitate maxima memorie RAM (GB) | 64GB |
| Frecventa memorie (MHz) | 2666/ 2400/ 2133 |
| Conectivitate | |
| Porturi USB 3.1 | 6x USB 3.1 |
| Porturi USB 2.0 Spate | 2 x USB 2.0 |
| LAN integrat | 1 x Intel® I219-V Gigabit LAN controller |
| Audio integrat | Realtek® ALC892 Codec |
| Interfata Serial ATA | SATA3 |
| Numar SATA | 5 x SATA 3 |
| Porturi USB | 2 x USB 3.1 Gen2 4 x USB 3.1 Gen1 6 x USB 2.0 |
| Audio | HD Audio |
| Conectori interni | 1 x 24-pin ATX main power connector 1 x 4-pin CPU fan connector 1 x 4-pin water pump fan connector 1 x 6-pin ATX PCIe power connector 1 x 8-pin ATX 12V power connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper 1 x Front panel audio connector 1 x Parallel port connector 1 x Series port connector 1 x TPM module connector 1 x Thunderbolt Add-on Card Connector 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports) 2 x Front panel connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 5 x 4-pin system fan connectors 5 x SATA 6Gb/s connectors |
| DVI-D | 1 |
| DisplayPort | 1 |
| M2 | 1 |
| PS/2 Mouse/Keyboard | 1 |
| RJ45 | 1 |
