| General | |
|---|---|
| Recomandat Gaming | Da |
| Placa audio integrata | 7.1 Audio with Realtek ALC897 |
| Chipset audio | Realtek ALC897 |
| RAID | 0, 1, 5, 10 |
| Placa video integrata | Necesita procesor cu tehnologia Intel HD Graphics |
| Placa retea integrata | 10/100/1000/2500 Mbps |
| Chipset retea | Realtek 2.5GbE LAN |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Interfata grafica | PCI Express x16 5.0 |
| SATA III | 4 |
| NGFF (M.2) | 2 |
| Procesor | |
| CPU Socket | 1700 |
| Chipset | B660 |
| Producator chipset | Intel |
| Procesoare suportate | Intel 12th Generation Core/Pentium Gold/Celeron |
| Memorie | |
| Model memorie | DDR4 |
| Capacitate maxima memorie RAM | 128 GB |
| Tehnologie | Dual channel |
| Frecvente suportate | 5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz |
| Sloturi memorie | 4 |
| Conectivitate | |
| Iesire optica S/PDIF | 1 |
| HDMI | 1 |
| DisplayPort | 1 |
| RJ-45 | 1 |
| USB 2.0 | 2 |
| USB 3.2 Gen1 tip A | 1 |
| USB 3.2 Gen2 tip A | 4 |
| USB tip C | 1 x USB 3.2 Gen 2x2 tip C |
| Suport audio | 7.1 |
| Audio jacks | 5 |
| Sloturi | |
| PCI Express x1 | 1 |
| PCI Express 3.0 | 1 (x4) |
| PCI Express 5.0 | 1 (x16) |
| Header USB 3.0 | Da |
| Specificatii Fizice | |
| Format | mATX |
| Dimensiuni (L x l, cm) | 24.4 x 24.4 cm |
