| Procesor | |
|---|---|
| CPU Socket | AM4 |
| Producator chipset | AMD |
| Model Chipset | AMD B450 |
| Chipset | AMD B450 |
| Memorie | |
| Memorii suportate | DDR4 |
| Sloturi memorie | 4 x DDR4 |
| Capacitate maxima memorie RAM (GB) | 64GB |
| Frecventa memorie (MHz) | 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz |
| Altele | |
| Accesorii incluse | 1 x M.2 Screw Package 1 x Supporting DVD 2 x SATA 6Gb/s cable(s) |
| Format | ATX |
| BIOS | 128 Mb Flash ROM ACPI 6.1 ASUS CrashFree BIOS 3 ASUS EZ Flash 3 F12 PrintScreen F3 My Favorite F4 AURA ON/OFF F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information Last Modified log Multi-language BIOS PnP SM BIOS 3.1 UEFI AMI BIOS |
| Dimensiuni (L x l, cm) | 30.5 cm x 23.4 cm |
| Altele | ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Model ASUS Exclusive Features : - AI Suite 3 - Ai Charger - PC Cleaner ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Slot - ASUS Q-DIMM ASUS Quiet Thermal Solution : - Stylish Fanless Design Heat-sink solution & MOS Heatsink - ASUS Fan Xpert 4 Core Overclocking Protection : - ASUS C.P.R.(CPU Parameter Recall) |
| Sisteme de operare testate | Windows® 10 64-bit |
| Conectivitate | |
| Porturi USB 3.1 | 2x USB 3.1 |
| Porturi USB 2.0 Spate | 4 x USB 2.0 |
| LAN integrat | Realtek® RTL8111H TUF LANGuard |
| Audio integrat | Realtek® ALC887-VD2 8-Channel High Definition Audio CODEC * |
| Numar SATA | 6 x SATA 3 |
| Porturi USB | 2 x USB 2.0 2 x USB 3.1 Gen 1 (blue) Type-A, 2 x USB 3.1 Gen 2 (teal blue)Type-A, |
| Audio | 3 x Audio jack(s) |
| COM | 1 x COM port header |
| Conectori interni | 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x AIO_PUMP connector (1 x 4 -pin) 1 x Aura RGB Strip Header 1 x COM port header 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Clear CMOS jumper(s) 1 x Front panel audio connector(s) (AAFP) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x System panel(s) 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 3 x Chassis Fan connector(s) (3 x 4 -pin) 6 x SATA 6Gb/s connector(s) |
| DVI-D | 1 x DVI-D |
| HDMI | 1 x HDMI |
| PS/2 Mouse/Keyboard | 1 x PS/2 keyboard/mouse combo port(s) |
| Porturi | 1 x 5Gb/s port(s) USB Type-CTM 1 x DVI-D 1 x HDMI 1 x LAN (RJ45) port(s) 1 x PS/2 keyboard/mouse combo port(s) 2 x USB 2.0 2 x USB 3.1 Gen 1 (blue) Type-A, 2 x USB 3.1 Gen 2 (teal blue)Type-A, 3 x Audio jack(s) |
| RAID | Support Raid 0, 1, 10 |
| RGB | Aura RGB Strip Headers |
| RJ45 | 1 x LAN (RJ45) port(s) |
| Sloturi | |
| Sloturi PCI | 1 x PCIe 3.0/2.0 x16 (x16 mode) 1 x PCIe 3.0/2.0 x16 (x8 mode) |
| Slot PCI-Express x1 | 3 x PCIe 2.0 x1 |
| Slot PCI-Express x16 | 1 x PCI Express x16 |
